Data Sheet 707020 JUMO GmbH & Co. KG • 36035 Fulda, Germany Page 2/12
Technical data for type 707020
Input for thermocouple
Input for resistance thermometer
Designation Range limits Range Accuracy a
Fe-Con L DIN 43710 -200 to +900°C -200 to +900°C 0.25%
Fe-Con J EN 60584 -210 to +1200°C -200 to +1200°C 0.25%
Cu-Con U DIN 43710 -200 to +600°C -200 to +600°C 0.25%
Cu-Con T EN 60584 -270 to +400°C -200 to +400°C 0.25%
NiCr-Ni K EN 60584 -270 to +1372°C -150 to +1372°C 0.25%
NiCr-Con E EN 60584 -270 to +1000°C -200 to +1000°C 0.25%
NiCrSi-NiSi N EN 60584 -270 to +1300°C -100 to +1300°C 0.25%
Pt10Rh-Pt S EN 60584 -50 to +1768°C -50 to +1768°C 0.25%
Pt13Rh-Pt R EN 60584 -50 to +1768°C -50 to +1768°C 0.25%
Pt30Rh-Pt6Rh B EN 60584 0 — 1820°C 400 — 1820°C 0.25%
MoRe5-MoRe41 0 — 2000°C 500 — 2000°C 0.25%
W3Re-W25Re D 0 — 2495°C 500 — 2495°C 0.25%
W5Re-W26Re C 0 — 2320°C 500 — 2320°C 0.25%
Shortest span Type L, J, U, T, K, E, N: 50°C
Type S, R, B: 500 °C
Type MoRe5-MoRe41: 500 °C
Type D, C: 500°C
Range start/end freely programmable range limits
Cold junction Pt100 internal or external cold junction (0 — 80°C is adjustable)
Cold junction accuracy ± 1°C
Sampling rate > 1 measurement per second
Input filter 1st order digital filter; filter constant adjustable from 0 to 125sec
Special features also programmable in °F; input isolated from output
a The accuracy refers to the maximum range span.
For small ranges, as well as for short spans, the linearization accuracy is reduced.
Designation Range limits Range Accuracy
Pt 100 EN 60751 -200 to +850°C -100 to +200°C
-200 to +850°C
±0.4°C
±0.8°C
Pt 100 JIS -200 to +649°C -100 to +200°C
-200 to +649°C
±0.4°C
±0.8°C
Pt 500 DIN -200 to +250°C -100 to +200°C
-200 to +250°C
±0.4°C
±0.8°C
Pt 1000 DIN -200 to +250°C -100 to +200°C
-200 to +250°C
±0.4°C
±0.8°C
Ni 100 -60 to +180°C -60 to +180°C ±0.8°C
Ni 500, Ni 1000 -60 to +150°C -60 to +150°C ±0.8°C
Connection circuit 2-, 3- or 4-wire
Shortest span 20°C
Range start/end freely programmable range limits
Sensor lead resistance
- for 3-, 4-wire connection
- for 2-wire connection
 11 per conductor
meas. resistance +
22 internal lead resistance
Sensor current
 0.6mA
Sampling rate > 1 measurement per second
Input filter 1st order digital filter; filter constant adjustable from 0 to 125sec
Special features also programmable in °F; input isolated from output
