Input for potentiometer
Input for DC voltage, DC current
Measurement circuit monitoring
Analog outputs
Custom linearization
Range Accuracy
up to 400

up to 2000

±500m

±1

Connection circuit 2-, 3- or 4-wire circuit
Shortest span 6

Resistance values freely programmable within the limits in 0.1
steps
Sensor lead resistance
- for 3-, 4-wire connection
- for 2-wire connection
 11 per conductor
meas. resistance +
22 internal lead resistance
Sampling rate > 1 measurement per second
Input filter 1st order digital filter; filter constant adjustable from 0 to 125sec
Special features also programmable in °F; input isolated from output
Range Accuracy Input resistance
0 — 100mV ±150
V
R
IN
> 10 M

Shortest span 5mV
Range start/end freely programmable within the limits
(up to 999mV in 0.1mV steps, above 1V in 1mV steps)
Sampling rate > 1 measurement per second
Input filter 1st order digital filter; filter constant adjustable from 0 to 125sec
Current input The current input can only be implemented in conjunction with an external shunt
(not included in delivery).
Example: a 5
shunt results in 0 — 20mA current input, with a programmed
voltage range of 0 — 100mV.
The accuracy corresponds to the voltage input
plus the inaccuracy of the shunt.
Resistance thermometer Thermocouple
Underrange linear drop to 3.8mA or 0mA (as per NAMUR recommendation 43)
Overrange linear rise to 20.5mA (as per NAMUR recommendation 43)
Probe short-circuit /
Probe/lead break 0mA or
 21.0mA (configurable)
0mA or
 21.0mA (configurable) a
a
Probe short-circuit recognition is not possible for thermocouple
Current output
Output signal proportional DC current 0 — 20mA or 4 — 20mA programmable
Transfer characteristic linear with temperature
inversion of the output signal
Max. burden 750

Burden error
 ± 0.02% / 100
1st order digital filter 0 — 125sec configurable
Step response 0 — 100 %
 2sec (with filter constant 0sec)
Switch-on delay 5sec (correct measurement after connecting the supply voltage)
Voltage output
Output range 0 — 10V
Accuracy ± 5mV
Linearity error ± 2mV
Load resistance
 2k
Load error ± 15mV
Ripple ± 1% referred to 10V, 0 — 90kHz
Number of calibration points 40 max.
Interpolation linear
