Data Sheet 70.6581 JUMO GmbH & Co. KG • 36035 Fulda, Germany Page 18/18
Order details
Standard accessories
- 1 Installation instructions B 70.6581.4 (B 70.6581.4.1 with extra code 444) and 1 Operating instructions B 70.6581.1
- 4 mounting brackets
- 1 control panel seal
- 1 CD with detailed operating instructions and additional documentation
Accessories - data sheet 70.9700
- CompactFlash memory cards and USB memory sticks. The CF cards and memory sticks specified by JUMO are tested and
designed for industrial applications. Other makes cannot be guaranteed.
- For further accessories, see data sheet 70.9700.
Basic type
706581/
Paperless recorder with Ethernet, USB and RS232/RS485 interfaces and
RS232 interface (to connect a barcode reader) and one relay
Basic type extensions
Software
0 No software package
1
With software package (setup program incl. USB cable, PC Evaluation software PCA3000,
PCA Communications software PCC)
Language for instrument texts
8 Factory setting (English/German)
9 Set to customer specification
1 2 3 Module slots
Slot 1 (bottom)
0 not used
2 3 analog inputs and 8 binary inputs/outputs
3 6 analog inputs
Slot 2 (middle)
0 not used
2 3 analog inputs and 8 binary inputs/outputs
3 6 analog inputs
Slot 3 (top)
0 not used
1 6 relay outputs
2 3 analog inputs and 8 binary inputs/outputs
3 6 analog inputs
Supply
33 100 - 240V AC +10/-15%, 48 - 63Hz
25 20 - 30V AC/DC, 48 - 63Hz
Extra codes
020 Lithium battery for memory buffering (ex-factory)
021 Storage capacitor (instead of extra code 020)
260 Math and logic module
267 PROFIBUS-DP interface
350 Universal carrying case TG-35 1
1 This extra code is available in combination with supply voltage 100—240V AC, not with low supply voltage.
UL and ATEX approvals not applicable. The protection type in the carrying case corresponds to IP20, outside IP20D.
444 Stainless steel front with touchpad
706581/ - - / ,...
2
2
List extra codes in sequence, separated by commas.
(Order code)
706581/ 1 8 - 3 2 1 - 33 / 020 (Order example)
