5 Settings
5.13 Adjusting the output level signal (output adjust U
2
, P , I
2
)
In the factory settings, the output level signal corresponds to the I
2
signal at
the output of the converter. It is thus proportional to the power in the load
(R=constant).
However, setting P or U
2
instead of the I
2
signals is also possible
v Chapter 5.2 „Setting switches and jumpers“
Output adjust
U
2
, P, I
2
The output level signal provides a voltage in the range of 0 to 10V
(corresponding to 0 to 100% of the variable being measured). The trimmer
„output adjust U
2
, P , I
2
“ on the front panel can be used to set the required
end value:
5.14 Process dependent load reduction
Switch S101-10 can be used to activate the process dependent load
reduction. The load is reduced depending on the resistance value R when
operating Molybdenum Disilicide heating elements. When the converter is
operating within rated limited, the load reduction amounts to approx. 10 %.
This must be taken into consideration when the converter operates outside its
rated limits (nominal voltage and current).
Power level output Internal switches
S4 S5 S6
U
2 1 0 0
P 0 1 0
I
2 0 0 1
Action Response
Turn „output adjust U
2
, P , I
2
“ trimmer
clockwise
End value increases
Turn „output adjust U
2
, P , I
2
“ trimmer
counter-clockwise
End value reduces
