JULABO HT60-M3 High Temperature Circulator User Manual
Page 52

Menu functions
52
Int.Programmer
Edit
>Delete
Print
Set Clock
>Delete Prof. 0
from Step 0
to Step 00
delete no
Delete Prof. 3
from Step 8
to Step 34
****delete****
Delete Prof. 3
from Step 8
to Step 34
>delete yes
Delete
• A flashing segment indicates that the respective profile number
needs to be entered in which one or more consecutive sections are
to be deleted.
• In lines 2 and 3 of the DIALOG DISPLAY (LCD) enter the numbers of
the sections to be deleted. Press enter
.
•
delete
no / yes
Press the P-key
to select the parameter „yes“ and press enter
.
Line 4 indicates the deletion.
Example:
Delete section 8 to section 34 in profile 3.
• Press escape
to return to the previous menu level.
Int.Programmer
Edit
Delete
>Print
Set Clock
>Print Profil 0
Print no
Print Profil 2
>Print yes
Print Profil 2
****print****
Profile 1
Step 0
not defined!
Step 1
50
00:08
Step 2
not defined!
Step 3
50
00:02
Step 4
not defined!
Step 5
100
00:10
Step 6
100
01:05
Step 7
not defined!
Step 8
not defined!
Step 9
80
00:10
Step 10
not defined!
Step 11
80
00:05
Step 12
not defined!
Step 13
not defined!
Step 14
20
00:30
Step 15
not defined!
etc.
Print
Each profile may be printed via the serial interface for control or
documentation.
• A flashing segment indicates that the number of the profile to be
printed needs to be entered.
•
no / yes
Press the P-key
to select the parameter „yes“ and press enter
.
Printing is indicated in line 2.
This printing example shows the profile given as example on page 51.
