14
tira36e1-a (0310) BPG/HPG400 v1.cp
The following table lists the services and parameters integrated in the Device Block
(
→ Appendix A for abbreviations).
ID Name Structure Data type Bytes Access Value Store
15 Device Block State Simple Unsigned8 1 1_R/W
2_R/W
16 Block Type Simple Octet string 4 1/2_R 1 N
17 Device Type Simple Visible string 8 1/2_R CG N
18 Standard Revision Level Simple Visible string 9 1/2_R E54-0997 N
19 Device Manufacturer
Identifier
Simple Visible string 20 1/2_R INFICON AG N
20 Manufacturer
Model Number
Simple Visible string 20 1/2_R e.g.
353-525 N
21 Software or Firmware
Revision Level
Simple Visible string 8 1/2_R e.g. 1.01 N
22 Hardware Revision Level Simple Visible string 8 1/2_R e.g. 1.0 N
23 Serial Number Simple Visible string 30 1/2_R e.g. 100 N
24 Device Configuration Simple Visible string 50 1/2_R e.g.
HPG400-SP N
25 Device State Simple Unsigned8 1 1/2_R V
26 Exception Status Simple Unsigned8 1 0_XI
1/2_R V
27 Exception Detail Alarm Record → below - 1/2_R V
28 Exception Detail
Warning
Record → below - 1/2_R V
202 Emission On Switch Simple Analogical to
data type
value (para-
meter 21) 1 1/2_R V
203 Sensor Calibration
Switch
Simple UINT8 1 1/2_R V
204 Common Exception
Detail Alarm 0
Simple UINT8 1 1/2_R V
205 Device Exception Detail
Alarm 0 … 3
Struct Array of
4 bytes 4 1/2_R V
206 Manufacturer Exception
Detail Alarm 0
Simple UINT8 1 1/2 _R V
207 Common Exception
Detail Warning 0
Simple UINT8 1 1/2 _R V
208 Device Exception Detail
Warning 1 … 4
Struct Array of
4 bytes 4 1/2 _R V
209 Manufacturer Exception
Detail Warning 0
Simple UINT8 1 1/2_R V
3.1 Device Block
