Rc1000 remote control – INFICON UL5000 Dry Helium Leak Detector User Manual
Page 17
General Information
17
iina
74
e 0
1
.f
m
te
chn
ica
l ha
nd
boo
k
(1
40
8)
1.4.2.5
RC1000 Remote control
The RC1000 is a wireless remote control that allows to operate the UL5000 from
distance up to 100 m. It provides the functions START, STOP/VENT, ZERO and
speaker volume, and displays leak rate in bargaraph or in chart mode. (see also
Technical Handbook RC1000.)
Measured values can be stored in an internal memory for up to 24 hours of recording
time. The data can easily be downloaded to a USB stick to save it.
An internal trigger can be set to provide a warning if the limit leak rates are exceeded.
An optical warning is shown on the display and an acoustic warning signal is
sounded on the integrated loudspeaker or the connected headphones.
The RC1000 remote control is housed in a robust housing to enable ergonomic
working. Magnets on the underside of the unit enable it to be attached to horizontal
or vertical metal surfaces.
The RC1000 also enables remote operation of the leak test device in question using
a connection cable of up to 28 metres in length.
Fig. 1-3 RC1000WL wireless remote control
