11. Technical specifications
Input data:
Measuring ranges:
16, 40, 100, 250, 400, 600 bar
Overload pressures:
32, 80, 200, 400, 800, 900 bar
Burst pressure:
300 % FS
Output data:
Accuracy:
EDS 1700-P: £ ±0.5 % FS max.
(display, analogue output)
EDS 1700-N: £ ±1.0 % FS max.
Repeatability:
EDS 1700-P: £ ±0.25 % FS max.
EDS 1700-N: £ ±0.5 % FS max.
Temperature drift:
EDS 1700-P: £ ±0.2 % / 10 K zero point max.
£ ±0.2 % / 10 K range max.
EDS 1700-N: £ ±0.3 % / 10 K zero point max.
£ ±0.3 % / 10 K range max.
Analogue output:
4 .. 20 mA, ohmic resistance £ 400 W
0 .. 10 V, ohmic resistance ³ 2 KW
Switching outputs:
Type:
4 relays with change-over contacts in 2 groups
(common supply of each group connected)
Switching voltage:
0.1 .. 250 V AC / V DC
Switching current:
0.009 .. 2 A
Switching capacity:
400 VA, 50 W
(for inductive load, use varistors)
Life expectancy of contacts:
³ 20 million min. load
³ 1 million max. load
Reaction time:
approx. 20 ms (without switching delay times)
Setting range of switching points 1.5 .. 100 % FS
Setting range of hystereses /
1 .. 99 % FS
switch-back points
Ambient conditions:
Temperature range of medium: -25 .. + 80 °C
Ambient temperature range:
-25 .. + 60 °C
Storage temperature range:
-40 .. + 80 °C
Nominal temperature range:
-10 .. + 70 °C
mark:
EN 50081-1, EN 50081-2,
EN 50082-1, EN 50082-2
Vibration resistance:
approx. 5 g
Shock resistance:
approx. 10 g
