Setting Display Setting Pre-
range setting
Display the unit (Unit) YES/NO NO
(only when set to "RANG" = "BAR"
or "PSI")
If set to "YES" the pre-set unit will
be displayed briefly every 7 seconds.
Decimal places (Point) 0 .. 0.0
(only when set to "RANG"="FREE") 0.000
Number of decimal places which the
EDS 1700 displays.
Lower display range (Range Low) -995 .. 0.0
(only when set to "RANG"="FREE") 9995
Lower display range limit
Upper display range (Range High) -995 .. measur-
(only when set to "RANG"="FREE") 9995 ing
Upper display range limit range
final
value
Calibration of sensor zero point (Calibrate) YES/NO ON
"YES": The base pressure is saved as
the new zero point. This is
possible in the range +/- 3% of
the unit’s nominal pressure.
"NEW" appears in the display
when a calibration is carried out in
the permissible range, otherwise
"Err" is displayed.
This function is useful for example if there
is always a residual pressure in the system
which should be displayed as 0 bar.
Please note:
Following a zero point calibration, for
example, on a 600 bar unit, a pressure
of up to 18 bar is displayed as 0 bar.
Before any work is carried out on the
hydraulic system, ensure that the system
is de-pressurised.
