User’s Guide Configuring your Computers
162
Fields on the
second setting
block Description
Rule Action Deny or allow traffic when matching this rule.
Direction Traffic forwarding direction.
Protocol There are 3 options available: TCP, UDP and ICMP.
Source IP
Address The source IP address assigned to the traffic on which
filtering is applied.
Source Subnet
Mask Subnet-mask of the source IP.
Source Port Starting and ending source port numbers.
Destination IP
Address The destination IP address assigned to the traffic on
which filtering is applied.
Destination
Subnet Mask Subnet-mask of the destination IP.
Destination Port Starting and ending destination port numbers.
Function Button Description
Apply Changes Click to save the rule entry to the configuration.
Delete Selected Delete selected filtering rules from the filter table. You
can click the checkbox at the Select column to select
the filtering rule.
Delete All Delete all filtering rules from the filter table.
