CRADLE - DELL E6500-E6530
INSTALLATION INSTRUCTIONS
Product Revision Form
If you need assistance or have questions, call Gamber-Johnson at 1-800-456-6868
7160-0202 Rev. E INST-439
Page 4 / 5
Accessories (see Figure 4)
Tools Needed
9/64" Hex-Key Wrench
11/21" Box Wrench
#2 Philips Screw driver
Screen Support
1. Secure the Screen Support to the left side of the Cradle using (2) #8-32 x .50
Socket Head Cap Screws and (2) #8 Flat Washers with a 9/64 Hex-Key Wrench.
2. Adjust the position of the Screen Support against the Computer Screen by loosening
the (2) #8-32 Socket Head Cap Screws and (2) #8-32 Nylok Nuts
Light
1. Secure the light to the right side of the Cradle using (2) #8-32 x .50 Socket Head
Cap Screws and (2) #8 Flat Washers with a 9/64" Hex-Key Wrench.
Isolator Plate
1. Secure (4) isolators using (8) #6-32 x .25 Pan Head Screws.
2. Secure the isolator p;ate using (4) #8-32 x .38 Pan Head Screws.
