Dome Settings 2 Submenu
The Dome Settings 2 submenu has additional configuration settings for the camera’s
advanced features, such as Window Blanking, Cruise Settings, and Motion Tracking
settings. It contains 7 submenus and no direct settings.
Dome Settings 2 -> Alarms Submenu
The Camera has built in to itself four alarm inputs which allow an external relay device to
trigger the camera to perform certain actions, and two alarm outputs which allow the
camera to trigger an external relay (For an alarm or lighting system, for example). The
alarms submenu allows you to configure the behavior of the four alarm inputs.
Alarm Number 1-4 allows you to select which input you’re configuring.
Alarm Action specifies what action the camera will take when triggered. The options it
gives are as follows:
None – No action taken
Preset – Go to the preset associated with the alarm number (IE : Alarm 1 goes to Preset 1,
Alarm 2 goes to Preset 2, etc.)
Pattern – Perform the pattern associated with the alarm number.
Auto/Random/Frame Scan – Perform the specified scan.
Cruise – Begin ‘Cruise’ setting through programmed presets.
Tracking – Begin Motion Tracking.
Alarm Aux allows that alarm to trigger one of the two relay outputs, such as a light or
siren.
Alarm Contact On/Off – Allows you to set if the alarm is normally open (On) or normally
closed (Off).
Dome Settings 2 -> Aux Submenu
This submenu controls the behavior of the two alarm outputs built in to the camera. The
two alarm outputs are used to trigger an external relay device. This menu controls how
long that device stays triggered by the camera.
Dwell Time 1 or 2 – This allows you to set the time, in seconds, that the AUX 1 or 2
outputs stays triggered. This will accept a value of 0 to 30 seconds.
Dome Settings 2 -> Password Submenu
This menu allows you to set a password to be able to access the camera menu. The
default password is ‘0000’.
