EUCHNER HBAS - Manual (Page 31)

EUCHNER Hand-Held Pendant Station
092491-07-01/09 Subject to technical modifications Page 31 / 34
10.3 Overview of commands
Identifier
byte
Command
byte
Description Parameter:
21H Cursor to the next character
22H Cursor to the previous character
23H Cursor one line down
24H Cursor one line up
25H Cursor at the start of the display
26H Cursor at the start of the line
27H Cursor at a specific position Line, column
28H Clear the current cursor position
29H Clear to the end of the line
2AH Clear to the end of the display
2BH Clear the entire display
2CH Clear a screen area
Start line, start column,
end line, end column
40H
Inverse on: all subsequent characters
are output inverse
41H Inverse off
42H
Flashing on: all subsequent characters
are output flashing
43H Flashing off
48H Definition of an item of text
Text number, font size, line,
column, text
49H Output of a previously defined item of text Text number
4AH Definition of an area
Area number, start line, start
column, end line, end column
4BH Clear a previously defined area Area number
4CH Inverse display of an area Area number
4DH Flashing display of an area Area number
4EH Inv. + flashing display of an area Area number
4FH Normal display of an area Area number
50H
51H Selection "small font"
Selection "large font"
6CH
80H ... FFH ASCII character set
23H
Status poll (keys 30H ... 44H and
error byte 31H ... 36H are sent)
52H
Continuous sound off
Continuous sound on
Pulsed sound on
Pulsed sound 0.5 s 30H
31H
32H
33H
53H Transfer parameter settings
PIN, priority,
pulse generator active,
pulse generator delay,
key assignment,
pulse generator frequency,
key click
none
54H Software reset
