Activation (Aktivierung):
Aktivierung
* aktiv
-> inaktiv
Auswahl
Zurück
Setting as to whether the pulse generator function is
to be activated:
Select using the
arrow -> with the
and accept using the key.
Leave the window with .
The setting currently saved is marked by the
*
(asterisk) .
Delay (Verzögerung Taste):
If a pulse generator key is pressed, then a 1 pulse
is output. (Section 8.)
Verzöger.Taste
Eingabe in ms:
0100
Auswahl
Zurück
If this pulse generator key is operated for longer than the
delay, then pulses are output with a constant frequency.
This delay (in milliseconds) for switching over from single
pulse to a constant pulse sequence can be selected here.
Select using the in the steps:
100, 250, 500, 1000, 1500, 2000,
and accept using the key.
Leave the window with .
Key assignment (Tastenbelegung) for pulse sequence left / right:
The keys for the pulse generator function can be defined
as required. Exceptions are the , ,
and <.> keys
Tastenbelegung
CCW CW
* <-- *
Auswahl
Zurück
The key to which the arrow <-- is pointing can be defined
by operating the corresponding key.
Each time the key is operated, the arrow toggles between
counter clockwise rotation (CCW) and clockwise rotation (CW).
The setting currently saved is marked by the * (asterisk) .
The assignment of the same key is not possible and will
be inhibited on saving.
Accept using the
key.
Leave the window with .
Frequency (Frequenz):
When a pulse generator key is pressed until the delay
has elapsed, pulses are output at a constant frequency in
pulses / second.
Frequenz
Impulsfrequenz
in Imp./Sek.
080
This frequency is selected using the
in the steps
10, 20, 30, 40, 48, 60, 80, 121, 242
Accept using the key.
Leave the window with .
