EUCHNER Hand-Held Pendant Station
Example: Pulse generator active
Cmd.
byte
PIN Priority Click
Pulse
gen.
active
Delay 1500 ms CW CCW Freq.121Hz
Control
system
STX 53H 36H 37H 38H 39H 30H 30H 31H 31H 35H 30H 30H 43H 42H 31H 32H 31H DLE ETX BCC
HBAS DLE DLE
Example: Pulse generator inactive
Cmd.
byte
PIN Priority Click
Pulse
gen.
active
Control
system
STX 53H 36H 37H 38H 39H 30H 30H 30H DLE ETX BCC
HBAS DLE DLE
Default parameters
When the hand-held pendant station is delivered, the following parameters are set:
Parameters Value
PIN 1234
Priority Control
system
Key click off
Pulse generator activation on
Pulse generator delay 1000 ms
Pulse generator CW key key
Pulse generator CCW key key
Pulse generator frequency 80 pulses/sec.
9.3 Software reset (command byte 54H)
The control system can initiate a software reset in the HBAS.
Therefor the command byte 54H must be sent.
The hand-held pendant station restarts. See section 5.
Example:
Control system STX 54H DLE ETX BCC
HBAS DLE DLE
