Softkeys
The ordering for softkeys available, when no channel is selected and when channels are selected,
have changed.
Changes to Ion
Tab Navigation
Ion now uses tabs for the displays. Ion’s [Swap] key will now perform the same actions as the [Tab]
key on Eos.
The Live/Blind display is open as tab 1. The playback status display is always open as tab 2.
Neither of these displays can be closed. With a single monitor, Ion will display a default tab 3, which
is a combined Live/Blind and playback status display.
Softkeys Available With No Channel Selected
Softkey Pg 1 Eos Ion Element
S1 N/A Query Select Last
S2 N/A Address Select Active
S3 N/A Snapshot Select Manual
S4 Address Highlight Park
S5 N/A Assert Fader Control
S6 N/A N/A Page Subs
Softkeys Available With a Channel Selected
Softkey Pg 1 Eos Ion Element
S1 Make Man Make Man Replace With
S2 Make Abs Make Abs Make Abs
S3 Flash Flash Chan Check
S4 Address Address Park
S5 Offset Offset Offset
S6 N/A Mark Flash
Softkey Pg 2 Eos Ion Element
S1
Replace
With Replace
With
N/A
S2 Lamp Ctrls Fan N/A
S3 N/A Assert Lamp Ctrls
S4 N/A Highlight N/A
S5 Chan Check Chan Check N/A
S6 Make Null Make Null N/A
