Csbib, Structural attachment fitting i - beam adapter – ERICO CSBIB - Structural Attachment Fitting, I-Beam Adapter User Manual
Page 2
THICKNESS
MIN TORQUE
A
#1
www.erico.com
FLANGE WIDTH
INSTRUCTION SHEET
CFS389_C
18 FT-LB (25 N-m)
Sway Brace assemblies are intended to be installed in accordance with NFPA-13
TECHNICAL SUPPORT:
© 2009 ERICO International Corporation
B
2 OF 2
B
C
CSBIB
STRUCTURAL ATTACHMENT FITTING
I - BEAM ADAPTER
and the manufacturer's assembly instructions.
MIN TORQUE
30 FT-LB (41 N-m)
#6
#5
#4
#3
#2
CSBIB is a Structural Attachment Fitting. It is intended to be combined with
CSBUNIV, TP225, and SB55N Structural Attachment Fittings, "Bracing Pipe" and a
CADDY® brand Sway Brace ("Braced Pipe") Fitting to form a complete bracing
assembly.
FLANGE
A
MIN INSTALL TORQUE
55ft-lb (75 N-m)
