Sheet2, Drawing view12, Drawing view15 – ERICO CADDY PYRAMID RL, PIPE RETAINERS User Manual
Page 2: Drawing view16, Drawing view17
1
Loosen both
top nuts to
dimension
shown
.25 6.4
3
Tighten both
top nuts
2
Twist into
position
TECHNICAL SUPPORT:
www.erico.com
CFS489_A
INSTRUCTION SHEET
2 OF 2
