Environmental Express AutoBlock III - Manual (Page 24)

PROGRAM TAB
IMPORT/EXPORT METHOD
Methods are stored in this directory MyComputer\LocalDisk(C)\HardDisk\Methods\
Methods are saved by METHOD NAME.TXT file example: 200.7 WATERS 50ML.TXT
Methods can also be written using notepad or word. Save as a text file (.txt) onto a USB stick
Basic operator knowledge of Microsoft Windows is required
Insert USB stick into USB slot near the touch screen
IMPORT
There are two ways to import methods
1. From the PROGRAM TAB, press OPEN button
Select MY COMPUTER from the side icons
Select TRAVELDRIVE (D:) and press the OPEN button
Select METHODS and press the OPEN button
Select method to import and press the OK button
Save the method using the SAVE procedures on the previous page
2. Press the START tab on the task bar
Select MY COMPUTER from the side icons
Select TRAVELDRIVE (D:) and press the OPEN button
Select method
Using the EDIT, COPY TO FOLDER
Select MyComputer\LocalDisk(C)\HardDisk\Methods, press the COPY button
EXPORT
There are two ways to export methods
1. From the PROGRAM TAB, open the method to be exported
press SAVE button
Select MY COMPUTER from the side icons
Select TRAVELDRIVE (D:) and press the OPEN button
Activate the keyboard, type method name in FILE NAME area
Press OK button
2. Press the START tab on the task bar
Select MY COMPUTER from the side icons
Double click LOCAL DISK(C:)
Double click HARDDISK
Double click METHODS
Select method to export
Using the EDIT, COPY TO FOLDER
Select TRAVELDRIVE (D:), press the COPY button
EXPORT LOG
Logs are stored in this directory MyComputer\LocalDisk(C)\HardDisk\Data\
Using the same procedure for Exporting Methods extracting method logs from the DATa directory.
Data logs are saved by MethodName.TXT Hour_Minute Month_Day_Year. DAT file
example: 200.7 WATERS 50ML.TXT12_30_FEB_01_09.DAT
ENVIRONMENTAL EXPRESS
For technical support call 1-800-745-8218 or send email to [email protected]
5528MANUAL-program Rev 3 24 9/15/09
