Environmental Express AutoBlock III User Manual

Page 23

PROGRAM TAB

EVERY METHOD

At the end of each method the following two commands need to be added

With the keyboard activated, press command area and type in the command string as follows:
Press the CONTINUE button and SAVE the method

enter: COLUMN DRAIN

enter: DISPENSE H2O(1) 10

OPEN

Opens directory where previous methods were saved MyComputer\LocalDisk(C)\HardDisk\Methods\

Select the OPEN button
Select a method from the directory
Press the OK button

SAVE

Save a new or edited method.

Select the Save button and activate keyboard
Type method name in FILE NAME area, Press OK button

Methods are stored in this directory MyComputer\LocalDisk(C)\HardDisk\Methods\

NEW

Clears the method command area enables operator to program commands to a new method

Select the NEW button
The methods field clears

EDIT

Allows the operator to modify current methods.

Method command area must have commands programmed on the screen
Select the EDIT button
Highlight the command to edit, activate the keyboard to make changes.
Cancel

You have canceled the command & return to the main PROGRAM TAB

Continue

Saves the change and returns to the main PROGRAM TAB to continue programming

ENVIRONMENTAL EXPRESS

For technical support call 1-800-745-8218 or send email to [email protected]

5528MANUAL-program Rev 3

9/15/09
