MANUAL TAB
The manual mode is just what it implies. In this mode, digestion functions (raising/lowering racks,
heating, cooling, injection, etc…) are performed individually by the analyst. The manual tab is used in
method development, troubleshooting and on going inspections, and other situations where hands-on
control of operations are required.
Manual tab screen with dual system
COLUMN & RACK DESIGNATION
Rack Movement (yellow section)
The (3) 18-position rack have been designed to hold 50ml vessels for a 54-well block.
Each rack can be moved up or down individual from one another.
By pressing the will raise the rack will lower the rack
Rack A located on the left, columns 1-2-3
Rack B center location, columns 4-5-6
Rack C located on the right, columns 7-8-9
All will raise or lower all three racks one at a time
After selecting
or
-A pop up message will appear: “RACK UP?”, Press Continue or Cancel button.
Cancel
A pop up message will appear: “CANCELLED?”, Press Continue button
You have canceled the command & return to the manual tab
Continue
The selected rack will move in the selected direction
A pop up message will appear: “RACK IS UP.”, Press Continue button
