Hornet and Bee Installation Guide Technical Specifications
MAN-HRBEIG (Ver. 1.304)
www.elmomc.com
57
4.3. Power Ratings
4.3.1. Hornet
Feature Units
15/
48
20/
48
1/
60
5/
60
10/
60
15/
60
20/
60
2.
5/
100
5/
10
0
15/
100
20/
100
Minimum supply voltage VDC 6 7.5 12
Nominal supply voltage VDC 42 50 85
Maximum supply voltage VDC 48 59 95
Maximum continuous power
output
W 600 800 50 240 480 720 960 200 400 1200 1600
Efficiency at rated power (at
nominal conditions)
% > 99
Maximum output voltage 95% of DC bus voltage at f=22 kHz
Auxiliary power supply VDC 11 to 95 VDC (up to 2.5 VA inc. 5 V/200 mA for encoder)
Amplitude sinusoidal/DC
continuous current (Ic)
A 15 20 1 5 10 15 20 2.5 5 15 20
Sinusoidal continuous RMS
current limit (Ic)
A 10.6 14.1 0.7 3.5 7 10.6 14.1 1.8 3.5 10.6 14.1
Peak current limit A 2 x Ic
Weight g (oz) 50 g (1.8 oz)
Dimensions mm (in) 55 x 15 x 46.5 (2.2" x 0.6" x 1.8")
Digital in/Digital out/ Analog in 6/2/1
Mounting method PCB Mount
