2. SPECIFICATIONS

2.1 GENERAL SPECIFICATIONS

Housing

DWP-102N plastic housing with s s bracket
DWP-102NS with Stainless steel housing

Power supply

110V 60Hz
built-in rechargeable battery
DWP-102N 6V4AH.
DWP-102NS 6V 1.3AH

Display

6 digits. 1

’ LED and 9 status indication

Keys

0-9 numeric and function combined keys
and TARE,ZERO,CE keys

Max input

15mV

ADC

Σ-Δ

Interface

2 ports RS-232 Output

Stabilization time

1 second typical

Operating temperature

5°C -35°C

Load cell drive voltage

5V/ Max 150mA

Other function

Real-time clock
and units conversion of kg ,lb, oz, g

Load cells

8 x 350

Ω Load Cells, or

16 x 700

Ω Load Cells

Load Cell Connection

Supports 4-wire and 6-wire Load Cell

Connections
