Chapter 3: Operating instructions
14 TruVision DVR 30 User Manual
Icon Description
Indicates the ending point of a video segment for archive while in playback mode.
The device is in PTZ mode.
The device is playing video forward.
The device is fast forwarding video playback.
The device is playing back video reverse.
The device is fast reversing video playback.
Video playback is on pause.
Video playback has reached the end of a video segment.
Indicates the amount of available hard disk space left.
Indicates the hard disk is full.
Camera commands
The camera commands appear when you point to Cameras on the mouse toolbar.
Click a camera number to display that camera in live mode.
Function commands
The function commands display when you point to Functions on the mouse toolbar.
Table 5: Mouse toolbar function commands
Icon Name Function
Main menu Displays the main menu
Multiscreen Toggles through the available multiscreen displays including full
screen, four-screen, nine-screen, and 16-screen.
Monitor Toggles between main and spot monitor. M indicates the main
monitor is currently selected. S indicates the spot monitor is
currently selected.
