SECTION 7: TEST MODE

7.1 Test Mode Description

The Test Mode allows manual control of the instrument outputs in order to test their
operation.

To access the Test Mode from the Control Mode, press the SCROLL key until Mod is
displayed. Press the DOWN key. This puts the control in Setup Mode. Press the
SCROLL key until tESt is displayed. Press the DOWN key to access the Test Mode.

A series of parameters is available by pressing the SCROLL key. The parameter tag
name will appear in the lower display with the upper display blank. Pressing the
SCROLL key again will display the tag name in the lower display and the parameter
value in the upper display. The value can then be edited by pressing the UP and
DOWN keys. To activate an output, press the UP key. To deactivate an output press
the DOWN key. Once the proper value appears press the SCROLL key. The next
parameter tag name will be displayed in the lower display with the upper display blank.

To return to the Setup Mode, press the UP key with the upper display blank. To return
to the Control Mode from the Setup Mode, press the SCROLL key until Ctrl is
displayed, then press the DOWN key. Exiting the Test Mode will deactivate all outputs
and revert control of the outputs back to the Control Mode.

Step

Description

Display Code

Available Settings

Test Output 1

tSt1

01 H
01 L

Test Output 2

tSt2

02 H
02 L

Test Output 3

tSt3

03 H
03 L

Test Communications

tSt4

OFF
r485
