4.7 Setup Modes
The Setup Modes contain parameters which configure the instrument and affect how
the control functions. To access the Setup Modes from the Control Mode, press the
SCROLL key until the lower display reads Mod. Press the DOWN key, then press the
SCROLL key to view the different modes available. The following sections contain
instructions for accessing and using the various Setup Modes. To return to Control
Mode, press the SCROLL key until CtrL is displayed, then press the DOWN key.
If a mode is not enabled (see Section 10) it will not be displayed in the Setup Mode list.
Table 4-2
Setup Modes
MODE
DISPLAY
DESCRIPTION
MANUAL
SECTION
Control
CtrL
Return to Control Mode
4
Tune
tunE
Contains PID tuning parameters
5
Alarm
ALA
Contains alarm parameters
6
Test
tESt
Provides testing parameters for outputs
7
Configuration
ConF
Contains parameters which control inputs and outputs
8
Calibration
CAL
Contains instrument calibration parameters
9
Enable
EnAb
Controls access to the various modes
10
PreTune
Pre
Turns the Pre-tune facility off and on
11
AutoTune
Auto
Turns the Auto-tune facility off and on
12
RaPIDTune
rAP
Turns the RaPID tune facility off and on
