COATS Kit 85009048, Bracket User Manual
COATS Equipment
Kit Components
Ref No.
Description
1
Lube Bucket Bracket
2
1/4-20x3/4 Hex Head Self Tap Screw
3
Lube Applicator
Installation Instructions
1. Install the lube bucket bracket on the side of the
machine using the supplied self-tapping screws pro-
vided in the kit.
2. Place the bucket of mounting cream (not supplied)
in the bracket.
85009063 00 01/08
© COPYRIGHT 2008 HENNESSY INDUSTRIES AND COATS ALL RIGHTS RESERVED PRINTED IN U.S.A.
Bracket Kit 85009048
For use with COATS Model
Rim Clamp
®
Tire Changers
Hennessy Industries • 1601 J.P. Hennessy Drive, LaVergne, TN 37086-3565 (800) 688-6359 • (615) 641-7533 • (615) 641-5104 FAX • www.ammcoats.com
1
2
3
Lube
Applicator
and Lube
Bucket
Install Using Self-
Tap Screws
