COATS Kit 85606376 Motorcycle Wheel Adapter User Manual
Page 4
8111865 01 02/09
© Copyright 1997 Hennessy Industries and COATS
All Rights Reserved
Printed in USA
Parts Listing
ITEM
PART NO.QTY
DESCRIPTION
1
85606377
1
Jaw Connector, 40mm
2
8111778
4
Spring
3
8111777
4
Screw, M8x25
4
8111776
4
Lock Nut
5
8111775
2
Screw, M6x70
6
8111774
2
Stopper
7
8111773
2
Lock Jaw
8
8111780
2
Screw, TSEI, M8x25
9
8111781
1
Key, Hexagonal, 15mm
11
8111863
2
Screw, VTCEI, M6x18
12
85606378
1
Wheel Holding Shaft
13
8111784
2
Centering Cone
14
8111785
1
Bushing, 17x14mm
15
8111786
2
Spacer
16
8111781
1
Collet for Shaft
17
8111789
2
Bushing - BMW Wheels
18
8111790
1
Bushing, 20x14mm
19
8111791
1
Bushing, 25x14mm
20
8111792
2
Cone - BMW Wheels
