Table 5 Modbus Holding Registers (continued)
Address Size Type Value Description Values
3069 2 Float
VF_HIGH_FILTER_
TAU_ARRAY_05
Tau Filter definition for VF.
3071 2 Float
VF_HIGH_FILTER_
TAU_ARRAY_06
Tau Filter definition for VF.
3073 2 Float
VF_HIGH_FILTER_
TAU_ARRAY_07
Tau Filter definition for VF.
3075 2 Float
VF_HIGH_FILTER_
TAU_ARRAY_08
Tau Filter definition for VF.
3077 2 Float
VF_HIGH_FILTER_
TAU_ARRAY_09
Tau Filter definition for VF.
3079 2 Float
VF_HIGH_FILTER_
TAU_ARRAY_10
Tau Filter definition for VF.
3081 2 Float VF_DAMPING_TAU Damping time in seconds for the damping filter for VF.
3083 2 Float
VF_SPIKE_FILTER_
PERCENT Defines delta of the previous measurement over the
range below which the flow rate is deemed valid.
3085 2 Float
GVF_LOW_FILTER_
DELTA_ARRAY_01
Delta Filter definition for GVF.
3087 2 Float
GVF_LOW_FILTER_
DELTA_ARRAY_02
Delta Filter definition for GVF.
3089 2 Float
GVF_LOW_FILTER_
DELTA_ARRAY_03
Delta Filter definition for GVF.
3091 2 Float
GVF_LOW_FILTER_
DELTA_ARRAY_04
Delta Filter definition for GVF.
3093 2 Float
GVF_LOW_FILTER_
DELTA_ARRAY_05
Delta Filter definition for GVF.
3095 2 Float
GVF_LOW_FILTER_
DELTA_ARRAY_06
Delta Filter definition for GVF.
3097 2 Float
GVF_LOW_FILTER_
DELTA_ARRAY_07
Delta Filter definition for GVF.
3099 2 Float
GVF_LOW_FILTER_
DELTA_ARRAY_08
Delta Filter definition for GVF.
3101 2 Float
GVF_LOW_FILTER_
DELTA_ARRAY_09
Delta Filter definition for GVF.
