CiDRA Passive Sonar Transmitters - Manual (Page 25)

Table 5 Modbus Holding Registers (continued)
Address Size Type Value Description Values
1080 1 Char
ALARM_CRIT_EXP
R_2
Boolean expression used for critical alarm. 0 = Blank, 1 = OR, 2 = AND
1081 1 Char
ALARM_CRIT_EXP
R_3
Boolean expression used for critical alarm.
2 = Blank, 3 = TMP, 4 = SPL, 5 =
VQ, 6 = SQ, 7 = LOG, 8 = OVL, 9
= FAL, 10 = FLW, 11 = GVF
1082 1 Char
ALARM_CRIT_EXP
R_4
Boolean expression used for critical alarm. 0 = Blank, 1 = OR, 2 = AND
1083 1 Char
ALARM_CRIT_EXP
R_5
Boolean expression used for critical alarm.
2 = Blank, 3 = TMP, 4 = SPL, 5 =
VQ, 6 = SQ, 7 = LOG, 8 = OVL, 9
= FAL, 10 = FLW, 11 = GVF
1084 1 Char
ALARM_MANUAL_C
LR Disables or enables manual clearing of alarms from front
panel with the ESC/EXIT Key.
0 = Disable, 1 = Enable
1501 2 Float DISP_PIPE_DIAM Pipe Inside Diameter (ID).
1503 2 Float PIPE_OD Pipe Outside Diameter (OD).
1505 2 Float WALL_THICKNESS Pipe Wall Thickness.
1507 2 Float VISCOSITY
Viscosity in Pascal seconds of the fluid at the operating
conditions. Used for Reynolds correction.
1509 2 Float
ALTITUDE_ABOVE_
SEA_LEVEL Altitude Above Sea Level in units defined by
'ALTITUDE_UNITS'.
1511 2 Float
LOW_FLOW_CUT_
OFF
Low flow cutoff as a % of flow measurement range
(defined by FLOW_MIN and FLOW_MAX). Will not
display or output flow reading if flow value is below this
setting.
1513 2 Float
HIGH_FLOW_CUT_
OFF
High flow cutoff as a % of flow measurement range
(defined by FLOW_MIN and FLOW_MAX). Will not
display or output flow reading if flow value is above this
setting.
1515 2 Float CUST_VOL_SCALE Multiplier for base flow units to create custom display.
1517 2 Float
CUST_TIME_SCAL
E
Multiplier for base time units to create custom display.
1519 2 Float
VF_QUALITY_DELT
A
Delta change from minimum quality at minimum flow
(MIN_QUALITY) to minimum quality at max flow
(MIN_QUALITY+ VF_QUALITY_DELTA).
20959-01 Rev 02 Page 3-10
