Table 5 Modbus Holding Registers (continued)
Address Size Type Value Description Values
1025 2 Char CUST_TIME_LABEL
Two character string used for display and logging of a
custom flow time unit.
Any Alpha
1027 1 Char
GVF_DECIMAL_PL
ACES Sets the number of decimal places used to display GVF
on the front panel.
0 - 6
1028 1 Char SOS_VOL_UNITS Selects units used to display and log SOS. 0 = ft, 1 = m
1029 1 Char DATE_FORMAT Selects date format
0 = US (mm/dd/yyyy), 1 = Euro
(dd/mm/yyyy), 2 = International
(yyyy-mm-dd)
1030 1 Char DEBUG_SETTINGS Selects debugging options 0 = 255
1031 1 Char WRITE_PROTECT
Enable or disable modifications to the transmitter FLASH
memory. When modifying this change only this for
proper operation.
0 = Disable, 1 = Enable
1032 1 Char Pre Amp Gain
Gain selection for the preamp. Set a value 0 thru 3 to
choose gain listed by 'Preamp Gain 0', 'Preamp Gain 1',
'Preamp Gain 2,' or 'Preamp Gain 3'
0 - 3
1033 1 Char
TLF_SENSOR_INP
UT_UNITS_1 Selects units used in translating the mA measured on
Sensor 1 input to units used internally. 0 = None, 1 = PSIg, 2 = kPAg, 3 =
BARg, 4 = C, 5 = F
1034 1 Char
TLF_SENSOR_INP
UT_UNITS_2 Selects units used in translating the mA measured on
Sensor 2 input to units used internally. 0 = None, 1 = PSIg, 2 = kPAg, 3 =
BARg, 4 = C, 5 = F
1035 1 Char
PRESS_INPUT_UNI
TS Selects units for pressure read from register 5001 -
Pressure Input. 0 = None, 1 = PSIg, 2 = kPAg, 3 =
BARg
1036 1 Char
TEMP_INPUT_UNIT
S Selects units for temperature read from register 5003 -
Temperature Input.
0 = None, 4 = C, 5 = F
1037 1 Char
EXTERN_INPUT_U
NITS_0 Selects units for value read from register 5005 - External
Input 1. 0 = None, 1 = PSIg, 2 = kPAg, 3 =
BARg, 4 = C, 5 = F
1038 1 Char
EXTERN_INPUT_U
NITS_1 Selects units for value read from register 5007 - External
Input 2. 0 = None, 1 = PSIg, 2 = kPAg, 3 =
BARg, 4 = C, 5 = F
1039 1 Char
EXTERN_INPUT_U
NITS_2 Selects units for value read from register 5009 - External
Input 3. 0 = None, 1 = PSIg, 2 = kPAg, 3 =
BARg, 4 = C, 5 = F
1040 1 Char
VF_NR_MAGNITUD
E_SEL
Selects flow noise reduction filter magnitude. 0 = Low, 1 = High
1041 1 Char
GVF_NR_MAGNITU
DE_SEL
Selects GVF noise reduction filter magnitude. 0 = Low, 1 = High
