Table 5 Modbus Holding Registers (continued)
Address Size Type Value Description Values
1042 16 Char
SENSORHEAD_SE
R_NUMBER
Sensor Head Serial Number. Any Alpha
1058 1 Char TOT_UNITS Selects units used to display and log total flow.
0 = gal, 1 = m3, 2 = ft3, 3 = l, 4 =
VF_VOL_UNITS
1059 1 Char TOTALIZER_MULT Selects totalizer multiplier. 0 = 1, 1 = k, 2 = M
1060 1 Char
TOT_LOW_CUT_EN
ABLE
Enables or disables totalizer lowcut. 0 = Disable, 1 = Enable
1061 1 Char
TLF_TOTALIZER_IN
PUT_SEL
Selects source of totalizer - VF or TLF. 0 = VF, 1 = TLF
1062 1 Char
PRIMARY_420_OUT
_OF_RANGE
Selects 4-20mA Channel 1 Out Of Range action.
0 = Hold, 1 = <4ma, 2 = =4ma, 3 =
>20ma
1063 1 Char
PRIMARY_420_PO
WER_SEL Selects 4-20mA Channel 1 External or Internal 4-20mA,
power.
0 = Internal, 1 = External
1064 1 Char
PRIMARY_420_OUT
PUT_SEL
Selects metric to be output on 4-20mA Channel 1.
0 = Flow Rate, 1 = SOS, 2 = GVF,
3 = Blank, 4 = TLF, 5 = Flow
Quality, 6 = SOS Quality
1065 1 Char
420_OVERRANGE_
MODE_01
Selects 4-20mA Channel 1 Overrange rail.
0 - Use
PRIMARY_420_OUT_OF_RANG
E setting when output is below/
above lowcut/highcut % (do not
rail), 1 - Rail 4-20mA output if
metric is below/above
lowcut/highcut % for channel 1
1066 1 Char
SECONDARY_420_
OUT_OF_RANGE
Selects 4-20mA Channel 2 Out Of Range action.
0 = Hold, 1 = <4ma, 2 = =4ma, 3 =
>20ma
1067 1 Char
SECONDARY_420_
POWER_SEL Selects 4-20mA Channel 2 External or Internal 4-20mA
power.
0 = Internal, 1 = External
1068 1 Char
SECONDARY_420_
OUTPUT_SEL
Selects metric to be output on 4-20mA Channel 2.
0 = Flow Rate, 1 = SOS, 2 = GVF,
3 = Blank, 4 = TLF, 5 = Flow
Quality, 6 = SOS Quality
20959-01 Rev 02 Page 3-8
