CiDRA Passive Sonar Transmitters - Manual (Page 14)

20959-01 Rev 02 Page 2-4
2.5 Other Registers
Coils and Discreet inputs are not used in the transmitter. All
configurations are performed with Holding Registers, and
measurements read from Input Registers.
2.6 Diagnostics
08/02 Read Diagnostic Register
•
Diagnostic Register Bits
Bit
Number
Description
0 STATUS_BIT_DEFAULTS
1 STATUS_BIT_DSP_DEAD
2 STATUS_BIT_DSP_NO_RESP
3 STATUS_PREAMP_FAILURE
4 SOS_SINGULAR_MATRIX_ERR
5 VF_SINGULAR_MATRIX_ERR
6 VFCENTROID_DIV0_ERROR
7 SOSCENTROID_DIV0_ERROR
8 NO_VALID_FREQ_POINTS
9 SENSOR_OVERLOAD_ERROR
10 VF_DATA_OVERANGE
11 SOS_DATA_OVERANGE
12 unused
13 unused
14 unused
15 unused
Table 3 Diagnostic Register Bits
2.7 Other Functions
2.7.1 17 Read Slave ID
Slave ID returned by this command is based on the software revision
of the transmitter as follows:
Software version V4.01.02 returns a Slave ID of 40102.
2.7.2 43/14 Read Device Identification
This function code returns three string objects as follows:
CiDRA Corp.
TB8-XX-XX-XX-XX
V4.01.02
