Table 5 Modbus Holding Registers (continued)
Address Size Type Value Description Values
1555 2 Float
SECONDARY_420_
OFFSET Constant offset applied to primary 4-20mA output for
calibration purposes.
1557 2 Float PULSE_MULT Pulse output multiplier.
1559 2 Float PULSE_LOW_CUT
Define measurement value below which pulse output will
not be updated.
1561 2 Float
ALARM_WARN_TE
MP_< Min band temperature threshold for warning alarm in
degrees C.
1563 2 Float
ALARM_WARN_TE
MP_> Max band temperature threshold for warning alarm in
degrees C.
1565 2 Float
ALARM_WARN_SP
L_<
Min SPL threshold for warning alarm in dB.
1567 2 Float
ALARM_WARN_SP
L_>
Max SPL threshold for warning alarm in dB.
1569 2 Float
ALARM_WARN_VF_
QUAL_<
Min VF Quality threshold for warning alarm.
1571 2 Float
ALARM_WARN_SO
S_QUAL_<
Min SOS Quality threshold for warning alarm.
1573 2 Float
ALARM_WARN_VF_
<
Min Vortical Flow Rate threshold for warning alarm in %.
1575 2 Float
ALARM_WARN_VF_
>
Max Vortical Flow Rate threshold for warning alarm in %.
1577 2 Float
ALARM_WARN_GV
F_< Min Gas Volume Fraction threshold for warning alarm in
%.
1579 2 Float
ALARM_WARN_GV
F_> Max Gas Volume Fraction threshold for warning alarm in
%.
1581 2 Float
ALARM_CRIT_TEM
P_< Min band temperature threshold for critical alarm in
degrees C.
1583 2 Float
ALARM_CRIT_TEM
P_> Max band temperature threshold for critical alarm in
degrees C.
1585 2 Float
ALARM_CRIT_SPL_
<
Min SPL threshold for critical alarm in dB.
1587 2 Float
ALARM_CRIT_SPL_
>
Max SPL threshold for critical alarm in dB.
20959-01 Rev 02 Page 3-12
