Table 5 Modbus Holding Registers (continued)
Address Size Type Value Description Values
1009 1 Char
SOS_LIQUID_SPEC
GRAV_SEL Selects use of pre-defined SOS Specific Gravity or a
custom value entered in 'SOS Specific Gravity'.
0 = 0.997 (Water), 1 = Custom
1010 1 Char
SOS_LIQUID_SOS_
SEL Selects use of pre-defined SOS Liquid Sound Speed or a
custom value* entered in 'SOS Liquid Sound Speed' 0 = 4910.4 ft/s (Water), 1 =
Custom
1011 1 Char
TLF_TEMP_INPUT_
SEL
Selects the source of the temperature used in GVF
calculations. 'Fixed' uses 'SOS Process Temperature',
'Sensor 1' uses the 4-20mA input channel 1, 'Sensor 2'
uses 4-20mA input channel 2, Protocol uses values
written to register 5003.
0 = Fixed, 1 = Sensor 1, 2 =
Sensor 2, 3 = Protocol
1012 1 Char
TLF_PRESS_INPUT
_SEL
Selects the source of the pressure used in GVF
calculations. 'Fixed' uses 'SOS Process Pressure',
'Sensor 1' uses the 4-20mA input channel 1, 'Sensor 2'
uses 4-20mA input channel 2, Protocol uses values
written to register 5001.
0 = Fixed, 1 = Sensor 1, 2 =
Sensor 2, 3 = Protocol
1013 1 Char SOS_TEMP_UNITS
Selects units used for input of 'SOS Process
Temperature' degrees.
0 = C, 1 = F
1014 1 Char
SOS_PRESS_UNIT
S
Selects units used for input of 'SOS Process Pressure'. 0 = PSIg, 1 = kPAg, 2 = BARg
1015 1 Char ALTITUDE_UNITS Selects units used for entry of 'Altitude'. 0 = ft, 1 = m
1016 1 Char DISP_LINE1
Selects measured value to be displayed on line 1 of the
LCD.
0 = Flow Rate, 1 = Flow Rate%, 2
= Totalizer, 3 = SOS, 4 = GVF, 5 =
Blank, 6 = TLF
1017 1 Char DISP_LINE2
Selects measured value to be displayed on line 2 of the
LCD.
0 = Flow Rate, 1 = Flow Rate%, 2
= Totalizer, 3 = SOS, 4 = GVF, 5 =
Blank, 6 = TLF
1018 1 Char VOL_UNITS Selects units used to display and log flow volume.
0 = m^3, 1 = l, 2 = gal, 3 = m, 4 =
ft, 5 = iga, 6 = ft^3, 7 = user
1019 1 Char TIME_UNITS Selects units used to display and log flow time. 0 = d, 1 = h, 2 = m, 3 = s, 4 = user
1020 1 Char CUST_VOL_UNITS Selects volume units used in calculation of a custom unit.
0 = m^3, 1 = l, 2 = gal, 3 = m, 4 =
ft, 5 = iga, 6 = ft^3
1021 1 Char CUST_TIME_UNITS Selects time units used in calculation of a custom unit. 0 = d, 1 = h, 2 = m, 3 = s
1022 3 Char CUST_VOL_LABEL
Three character string used for display and logging of a
custom flow volume unit.
Any Alpha
20959-01 Rev 02 Page 3-6
