Table 4 Modbus Input Registers (continued)
Address Size Type Value Description Notes
69 2 Float Total TLF Fraction
Floating point fraction to be added to 'Total TLF Carry' *
100 to calculate full resolution total TLF.
Fractional part of totalizer. Add
this number to Total TLF Carry *
100 to calculate full total.
71 2 Float Output 1 Spare Output 1.
73 2 Float Output 2 Spare Output 2.
75 2 Float Output 3 Spare Output 3.
77 2 Float Output 4 Spare Output 4.
1001 2 Long System Status Refer to manual for description of individual bits.
1003 2 Long Sensor 1 Max Sensor 1 maximum in A/D bins.
1005 2 Long Sensor 2 Max Sensor 2 maximum in A/D bins.
1007 2 Long Sensor 3 Max Sensor 3 maximum in A/D bins.
1009 2 Long Sensor 4 Max Sensor 4 maximum in A/D bins.
1011 2 Long Sensor 5 Max Sensor 5 maximum in A/D bins.
1013 2 Long Sensor 6 Max Sensor 6 maximum in A/D bins.
1015 2 Long Sensor 7 Max Sensor 7 maximum in A/D bins.
1017 2 Long Sensor 8 Max Sensor 8 maximum in A/D bins.
1019 2 Long Sensor 1 Min Sensor 1 minimum in A/D bins.
1021 2 Long Sensor 2 Min Sensor 2 minimum in A/D bins.
1023 2 Long Sensor 3 Min Sensor 3 minimum in A/D bins.
1025 2 Long Sensor 4 Min Sensor 4 minimum in A/D bins.
1027 2 Long Sensor 5 Min Sensor 5 minimum in A/D bins.
1029 2 Long Sensor 6 Min Sensor 6 minimum in A/D bins.
1031 2 Long Sensor 7 Min Sensor 7 minimum in A/D bins.
1033 2 Long Sensor 8 Min Sensor 8 minimum in A/D bins.
1035 2 Long Total Flow Carry
Signed long portion (* 100) to be added to 'Total Flow
Fraction' to calculate full resolution total flow.
Carry part of totalizer. Add this
number * 100 to Total Flow
Fraction to calculate full total.
1037 2 Long Total TLF Carry
Signed long portion (* 100) to be added to 'Total TLF
Fraction' to calculate full resolution total TLF.
Carry part of totalizer. Add this
number * 100 to Total TLF
Fraction to calculate full total.
20959-01 Rev 02 Page 3-2
