CiDRA Passive Sonar Transmitters - Manual (Page 26)

Table 5 Modbus Holding Registers (continued)
Address Size Type Value Description Values
1521 2 Float
SOS_QUALITY_DEL
TA
Delta change from SOS minimum quality at minimum
SOS (SOS_MIN_QUALITY) to minimum quality at max
SOS (SOS_MIN_QUALITY+ SOS_QUALITY_DELTA).
1523 2 Float
YELLOW_QUALITY
_PERCENT
Percentage of VF quality or SOS quality (depending on
op mode) below which the display will indicate a 3 level
of 'YEL', if configured to display 3 level quality.
1525 2 Float TOTAL_LOW_CUT
Define low limit of totalizer. Input as % of flow rate.
Readings below this value will not be totalized.
1527 2 Float REYNOLDSC0 Volumetric flow calibration coefficient C0.
1529 2 Float REYNOLDSC1 Volumetric flow calibration coefficient C1.
1531 2 Float REYNOLDSC2 Volumetric flow calibration coefficient C2.
1533 2 Float
TLF_SENSOR_INP
UT_SCALE_1
Sets multiplier used to scale the 4-20mA input Sensor 1.
1535 2 Float
TLF_SENSOR_INP
UT_SCALE_2
Sets multiplier used to scale the 4-20mA input Sensor 2.
1537 2 Float
TLF_SENSOR_INP
UT_OFFSET_1 Sets offset used to calculate the 4-20mA input Sensor 1
value.
1539 2 Float
TLF_SENSOR_INP
UT_OFFSET_2 Sets offset used to calculate the 4-20mA input Sensor 2
value.
1541 2 Float
PRIMARY_420_HIG
H_END
Define high (20mA) end of primary 4-20mA output.
1543 2 Float
PRIMARY_420_LO
W_END
Define low (4mA) end of primary 4-20mA output.
1545 2 Float
PRIMARY_420_SCA
LE Multiplier applied to primary 4-20mA output for
calibration purposes
1547 2 Float
PRIMARY_420_OFF
SET Constant offset applied to primary 4-20mA output for
calibration purposes.
1549 2 Float
SECONDARY_420_
HIGH_END
Define high (20mA) end of primary 4-20mA output.
1551 2 Float
SECONDARY_420_
LOW_END
Define low (4mA) end of primary 4-20mA output.
1553 2 Float
SECONDARY_420_
SCALE Multiplier applied to primary 4-20mA output for
calibration purposes.
20959-01 Rev 02 Page 3-11
