101

Cold Water Fill Piping Sub-assembly

1

100209

NIPPLE,1/2"NPT X CLOSE,BRASS

1

2

100500

VACUUM BREAKER,1/2" NPT BRONZE

1

3

100704

NIPPLE,RTOE,1/2"NPT X 1 3/4"LG.,SST

1

4

100709

LOCKNUT,1/2" NPT,BRASS

1

5

102435

ELBOW, 1/2"NPT x 90 DEG,BRASS

1

6

102436

ELBOW,1/2"NPT X 90, SST

1

7

102438

ELBOW,STREET,1/2"NPT X 90, BRASS

3

8

102485

NIPPLE,1/2"NPT X 1 1/2"LG.,BRASS

1

9

102582

NIPPLE,1/2"NPT X 7 1/2"LG.,BRASS

1

10

110768

STRAINER,LINE,3/4"NPT BRONZE FEMALE

1

1
---
---

113352

VALVE 1/2" NPT SOLENOID 115V

1

108349 REPAIR KIT

113392

REPAIR KIT, 1/2" SOLENOID VALVE

A/R

113357

COIL SOLENOID, 1/2" 115VAC

A/R
