System Setting
60 |
System Setting
- NORMAL : The disk is in a normal state.
- CHECK : The disk has an error so that you need to check the disk or the connection cables of the disk.
If you leave the problem unresolved, no recording may be enabled. So it is recommended that you replace the
disk immediately.
- ERROR : The disk fails or is unable to use due to an error of the disk or the cable. The disk should be replaced
immediately.
Contact the retailer or the customer service to replace the disk.
i
S.M.A.R.T CHECK INTERVAL : Specify the
S.M.A.R.T check interval.
Click to start checking.
3. To apply the change, click in the bottom of
the screen.
4. When done, press the [EXIT] button on the remote
control or click in the lower screen. The
confirmation message appears and you will return to
the previous menu.
Event Setup
Define various events, and specify the conditions to notify the user in various ways.
\ \ Alarm Out
Specify the alarm output conditions with the work schedule.
Alarm Out
1. From - , select
.
2. Use the [ ▲▼◀▶ /ENTER] buttons on the remote
control or use the mouse to select
and configure the related settings.
i
NAME : You can rename the alarm.
i
OPERATION : Set the alarm output mode.
- N/O (Normal Open) : It normally stays Open.
However, if an event occurs, it will switch to Close.
- N/C (Normal Close) : It normally stays Close.
However, if an event occurs, it will switch to Open.
i
DURATION : Specify the duration of the alarm
output.
- TRANSPARENT : Keep the alarm out for as much time as the event lasts.
- UNTIL KEY : Keep the alarm out until a mouse or remote control button is pressed.
- 5 ~ 300 SEC : Keep the alarm out for as long as specified.
i
TEST : Forcibly output the alarm for the test purpose.
3. To apply the change, click in the bottom of the screen.
4. When done, press the [EXIT] button on the remote control or click in the lower screen. The confirmation
message appears and you will return to the previous menu.
