Model 601GAS burner — Instruction manual
Carlin part number MN601GAS Rev. 04/24/09
– 24 –
Where appliance instructions differ from this manual, follow the appliance instructions.
9. Replacement parts – Burner
Item
number
Description Part
number
1 Air tube with gasket and flanged door assembly; welded appliance flange shown (specify
appliance application and overall length of air tube) —
Air tubes will be type B, C or D
Combustion heads will be type 11, 21, or 31 (1” gas train connection) or type 12, 22, or 32
(1¼” gas train connection) Consult factory
2 Gas manifold (specify overall length of air tube and input range required) Consult factory
2a Gas manifold gasket 1” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1¼” . . . . . . . . . . . . . . . . . . . . . . . . . . . .
99260
99430
3 Flanged door nuts (four required) 28357
4 Blower housing (with cover and pressure augmenter) NA
5 Blower cover NA
7 Blower wheel 6 ¼“ diameter x 4“ deep 98857
8 Motor Carlin PSC, 1/2 hp, 3450 RPM
Marathon, 1/2 hp, 3450 RPM
Consult factory
27706S
9 Combustion head For 11, 12, 21 and 22 assemblies
For 31 and 32 assemblies
99147
99427
9a Static disc — Built into “1x” and “2x” heads (non-removable); not used in “3x” heads NA
9b Diffuser plate (1x heads only) 99162
Combustion head assemblies “11” combustion head assembly
(includes items shown on next page) “12” combustion head assembly
“21” combustion head assembly
“22” combustion head assembly
“31” combustion head assembly
“32” combustion head assembly
99294
99535
99295
99536
99532
99516
9c Retainer bolt (1x and 2x heads only, included with head) NA
10 Electrode/flame rod bracket assembly Large . . . . . . . . . . . . . . . . . . . . . . . . . . .
Small . . . . . . . . . . . . . . . . . . . . . . . . . .
99153
99155
11a
11b Ignitor electrodes Left . . . . . . . . . . . . . . . . . . . . . . . . . . .
Right . . . . . . . . . . . . . . . . . . . . . . . . . . .
99292
99293
12 Flame rod 99161
13 Airflow switch assembly (sensing lines not shown, but included with kit)
Airflow switch
High pressure sense line
Low pressure sense line
98521
99471
99472
14 Door interlock switch and mounting screws 99261KIT
15 Ignitor, Carlin electronic Model 41000 with cover plate 41000S0LC
16 Burner junction box, 4” x 4”, with grommet, lock washer, conduit nipples (to burner housing) 99198CBLK
16a J-box mounting bracket 99501B
17 Primary control, Carlin 60200FR microprocessor flame rod control 602002FR943S
18 Optional adjustable forced draft flange 99255
19 Air inlet screen 99438
