BAND-IT XE9229 Tensioning Tool User Manual
Xe9229 cable tie tensioner, Operating instructions
BAND-IT-IDEX, Inc.
A Unit of IDEX Corporation
4799 Dahlia Street
Denver, CO 80216-3070 USA
P: 1-800-525-0758
F: 1-800-624-3925
Document # P97487 Rev. -
© Copyright
BAND-IT-IDEX, Inc. 2009
All rights reserved
www.BAND-IT-IDEX.com
Page 1 of 1
XE9229
Cable Tie Tensioner
1. Loop cable tie around bundle. Insert the 2. Slide the tail into the side entry and
tail into the buckle and pull tight by hand. position the tool as shown. Position the
tool against the base of the buckle.
3. Squeeze the handle to tighten tie to the 4. Maintain final handle pressure and
desired tension. rotate cutter bar upward for cut off.
Note: XE9229 is a non-warranty item.
Operating
Instructions
