• DST Specifications (continued)
DST-9421
Application Dry stable
Environments
Operating Range (ft.) 0.5 to 35
Enclosure PC/PET
Transducer Type Electrostatic
Transducer Material Gold-Kapton
Ratings NEMA 12
Approvals n/a
Operating Temp -40 to 70ºC
Internal Temp Comp. Yes
Accuracy 0.25% of range
Dimensions L x D (in.) 5.5 x 2.5
Beam Pattern 9° off axis
Cable 2-conductor
AutoSense SOFTWARE ~The AutoSense software is a built-in feature available
with the DST sensor models listed above. It provides automatic sensitivity
adjustment and is preferable in tank and level applications. Please use the above
part numbers when ordering a DST with the AutoSense option.
