Rev. A4, 10/08 DCR-1005 and DCR-1006
33
Automation Products Group, Inc.
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
• DCR Specifications
DCR-1005 DCR-1006
Outputs 4 relays (10 A 110 VAC) 4 relays (10 A 110 VAC)
with isolated 4-20 mA.
Supply Voltage 24 VDC or 110/220 VAC 24 VDC or 110/220 VAC
Total Current 0.1 A 0.1 A
Draw
Housing Poly-Carbonate Poly-Carbonate
Rating NEMA 4X, IP65 NEMA 4X, IP65
Dimensions (in.) 6.25 x 3.125 x 2.25 6.25 x 3.125 x 2.25
Resolution Maximum of 0.1 in. Maximum of 0.1 in.
(2.5mm) (2.5mm)
Display 4 character digital LCD 4 character digital LCD
24 VDC Output 200 mA current max. 200 mA current max.
Operating Temp -30 to 60°C -30 to 60°C
Sample Rate 10 sec to 80 msec. 10 sec to 80 msec.
Adjustments Programmable modes Programmable modes
Connector Terminal Strip Terminal Strip
Sensor Coaxial “F” connector or Coaxial “F” connector or
Connector 2-conductor cable 2-conductor cable
