Rev. A4, 10/08 DCR-1005 and DCR-1006
35
Automation Products Group, Inc.
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
DST-3431 DST-5111
Application Wet corrosive Wet corrosive
Environments Environments
Operating Range (ft.) 1.25 to 50 4 to 72 inch
Enclosure PC/PET PC/PET
Transducer Type Ceramic Ceramic
Transducer Material PC/PET PVDF
Ratings NEMA 4X NEMA 6P/IP65
Approvals n/a n/a
Operating Temp -40 to 60°C -30 to 60ºC
Internal Temp Comp. Yes Yes
Accuracy 0.25% of range 0.25% of range
Dimensions L x D (in.) 7.5 x 3.5 4.5 x 3
Beam Pattern 9° off axis 9° off axis
Standard Cable 2-conductor 2-conductor
• DST Specifications (continued)
