• Wiring
Step 1: Depending on the DST cable version (coax or 2-conductor), connect
the DST to the DCR Controller by way of the coaxial ‘F’ connector located on
the outside of the DCR box, or use the terminal strip located inside the DCR box.
The DST sensors can be mounted up to 2000 feet from the controller.
Step 2: To obtain access to the DCR’s terminal strip, remove the DCR’s
polycarbonate cover by turning the 4 screws counterclockwise 1/4 turn. Remove
the display board by removing the four 4-40 screws to expose the terminal strip.
Step 3: The DCR-1005 and DCR-1006 is shipped from the factory configured
for 120 VAC input power. If 24 VDC or 230 VAC is to be used, change the
jumpers on the bottom board. A soldering iron will be required for this operation.
The jumpers are soldered into pads located on the bottom board and labeled J4.
The pads are labeled 1 through 6.
INPUT POWER JUMP JUMP
24 VDC 1-2 5-6
120 VAC 2-3 4-5
240 VAC 3-4 N/A
Step 4: Wires can be pulled into the DCR-1005 and DCR-1006 through the
strain reliefs on the enclosure. The screw terminal can be wired using solid or
stranded wire between 16 - 22 AWG. Wires should be stripped, leaving a 0.4 in.
bare wire. For wiring the 2-conductor DST, connect the red wire to DST (+) and
the black and shield wire to the DST GND.
Step 5: Perform an internal check to ensure that all wires are properly
connected and secured.
Step 6: Secure the Display Board and make the power connection. The LCD
should light.
TRIP 1 TRIP 2 TRIP 3 TRIP 4 DST 4-20 24V 110-220 VAC
24VDC
INPUT
O R
COM COM COM COM N.C. N.O. N.C. N.O. N.C. N.O. N.C. N.O. 24V L2 L1 GND DIG GND GND
Digital In
4-20(+) 4-20(-) DST(+)
