• DST Specifications
DST-1002 DST-2421
Application Wet corrosive Wet corrosive
Environments Environments
Operating Range (ft.) 1.5 to 35 1 to 25
Enclosure PVC PC/PET
Transducer Type Ceramic Ceramic
Transducer Material PVC PVDF
Ratings NEMA 6P/IP65 NEMA 4X
Approvals Class I, Div. 1 n/a
Operating Temp -30 to 60°C -40 to 60ºC
Internal Temp Comp. Yes Yes
Accuracy 0.25% of range 0.25% of range
Dimensions L x D (in.) 7 x 3.5 7 x 2.5
Beam Pattern 9° off axis 9° off axis
Standard Cable Coaxial RG-6 2-conductor
