Allen&Heath Scepter USER GUIDE User Manual
Page 31
Audio Owner Manual
Section 4
greater. The return impedance is
Ohm.
L/R Bus In
This
unbalanced jack is used to inject signals into the Left Right mix
amps. Use this jack when stacking 2 mixers together. This allows the Slave mixer
outputs to get to the Master mixer without tying up input channels or returns. The
nominal level is -2dBu with an input impedance of 33k Ohm.
26
