Section 2
MASTER
MASTER CONNECTIONS
0
PIN 1 LIFT
PIN 1
LIFT
Used to disconnect pin 1 from the MONO output connector.
Used to eliminate ground loops.
MONO BAL OUT
Male XLR-3 (Pin 2 Hot). Self Compensating Electronically
Balanced. Controlled by Mono Out Level pot. Normally
derived from mix of Pre-Fader Left &
Options
Section). Nom level of
Capable of
output
into 600 ohms or greater.
AUX OUT
A
AUX OUT
B
AUX OUT
C
AUX OUT
D
MONITOR
OUT
0
AUXAUNBALANCEDOUT
Jack. Controlled by Aux A Master. Nom level of
capable of
into 600 ohms or greater.
AUXBUNBALANCEDOUT
Jack Controlled by Aux A Master. Nom level of
capable of
into 600 ohms or greater.
AUXCUNBALANCEDOUT
Jack. Controlled by Aux A Master. Nom level of
capable of
into 600 ohms or greater.
AUXDUNBALANCEDOUT
Jack. Controlled by Aux A Master. Nom level of
capable of
into 600 ohms or greater.
STEREOUNBALANCEDOUT
Stereo Jack; Tip is Left, Ring is Right. Controlled by
Stereo Out Level pot. Normally derived from Pre-Fader Left
Options Section). Capable of
into 600
ohms or greater.
MONITOR UNBALANCED OUT
Stereo Jack; Tip is Left, Ring is Right. Controlled by
Monitor Level pot. Signal follows Monitor Select switch and
Auto-PFL. Capable of
into 600 ohms or greater.
14
