Section 3

Monitor Select and Level

This section selects the signal for the HEADPHONE OUTPUT on the front

panel and the MONITOR OUTPUT on the rear panel. It also routes the selected
signal to the LED Meters. If no switches are selected (and no PFL LED illuminated),

this signal is the LEFT/RIGHT output of the console. When a monitor select switch

is depressed, it routes the selected signal to the Meters, Headphones and Monitor
Output. The

control sets the volume to the two outputs, but has no effect on

the meter. In the event that multiple switches are selected, the switch closest to the

BOTTOM of the panel has priority. When any PFL switch is selected, the PFL ON
LED will illuminate and the

signal will override the selected monitor signal;

multiple PFL switches mix together. When all PFL switches are released, normal
monitoring resumes.

Headphone Jack

Accepts stereo headphones of 75 ohms or greater. Output source and level as

described above.
