AirLive WL_5470AP User’s Manual
26
4.4 Bridge Mode Setting
Alias Name You can set the alias name for this device. limited not exceed 32 characters.
Disable Wireless
LAN Interface
Check the box to disable the Wireless LAN Interface, by so doing, you won’t be
able to make wireless connection with this Access Point in the network you are
located. In other words, this device will not be visible by any wireless station.
Band You can choose one mode of the following you need.
~ 2.4GHz (B): 802.11b supported rate only.
~ 2.4GHz (G): 802.11g supported rate only.
~ 2.4GHz (B+G): 802.11b supported rate and 802.11g supported rate. The
default is 2.4GHz (B+G) mode.
Channel Number In Bridge mode, both wireless AP/Router device need set to the same Channel
number.
Security Please refer the AP mode settingsÆ Security for details.
But bridge mode are not supported with RADIUS 802.1x authentication.
WDS Security To enable security between wireless AP/Router , you can select WEP 64bits, WEP
128bits, WPA (TKIP), WPA2(AES) for data encryption.
For WEP encryption, Select ASCII if you are using ASCII characters. Select HEX if
you are using hexadecimal numbers (0-9, or A-F).
For WPA/WPA2 encryption, you need enter the Pre-Shared Key Information for
the authentication purpose.
